High Quality Vacuum Brazed Diamond Engraving Drill Bit for Stone CNC Router Bits

Basic Info.

Customized	Customized
Type	Cutting Tool
Material	Cemented Carbide
Certification	ISO 9001:2008
Delivery Time	7-10 Working Days
Shipment	FedEx, DHL,TNT,EMS,etc
Coating	Nano, Tiain, Aitin, Crn, Aicrxn
Helix Angle	35/45 Degree
Processing Form	Side,Steps,Right Angle Slot
Transport Package	1PC in a Plastic Tube, 10PCS a Group
Trademark	RV
Origin	Zhuzhou. China
HS Code	8207709000
Production Capacity	100000pieces/Year

Product Description

Products Raw Material Description: We can provide you with product selection or customized services from the following aspects.
Endmill series:
High-performance general machining with unequal pitch. High-performance general. General milling. Machining hardened material. Machining copper. Machining aluminum. Machining of hard-to-cut materials

End mill type: High-feed-rate. Corrugated edge. Radius. Ball nose. The sharp flat end. Corner protection flat end.
Structure type: Tiny diameter. Straight neck. Taper neck. Standard.
Coating type: Super nanometer crystal TiAlCrN coating. Super crystal nano heat resistant. TiAlN coatings. Nano TiAlN coating. TiAlN coating. AlTiN coating. CrN coating.

Grade	ISO Range	WC+Co(%)	WC grain size(um)	Density(g/cm3)	Hardness		Properties&Application
					Hv30	HRA
RV06U	K05-K10	93.5+6.5	0.6	14.85	1890	93.5	High cutting speed milling. For drilling, milling of plastic composites, PCB, ceramics, woods, and MDF.
RV09U	K10-K20	91+9	0.4	14.50	1890	93.5	High cutting speed milling, finishing Hardness steel, plastics, fiber-reinforced materials, HRC55-65.
RV10S	K20-K40	90+10	0.8	14.42	1600	91.5	High cutting speed milling, and drilling For general usage, suitable for all kinds of material below HRC45.
RV12S	K20-K40	88+12	0.6	14.12	1580	91.2	Specially designed for machining stainless steel. For use on stainless steel, nickel-based alloys, titanium alloy, and special alloy.
RV25S	K20-K40	88+12	0.4	14.10	1750	92.5	Suitable for finishing processing, and roughing of steels with hardness between 45 and 55HRC, steels for surface treatments, nickel alloys.
RV30S	K20-K40	88+12	0.6	14.10	1680	92.0	Perfect balance for hardness and toughness. For general usage and can provide an extremely long life.

Machining operation: Side face. Step shoulder. Straight slot. Deep flattened slot. Profile. Cavity. Ball nose slot. Deep ball nose slot. Radius shoulder. Radius corner slot. Workpiece material: Carbon steel. Alloy steel. Pre-hardened steel, Hardened steel. Stainless steel. Cast iron, Nodular cast iron. Copper alloy. Aluminum alloy. Titanium alloy. Heat resistant alloy.

Our products with ISO 9001 approved, about over 500 kinds of milling cutters for you to choose from, of course, can also be customized according to your company's needs, welcome send inquiry to us.


Whether you know exactly what type of carbide end mill is required or need to discuss the options with an expert. we are here to help.

Contact us for more information.
